The Melbourne International Exhibition - Amended plan of "The Dome"/ Section thro dome/ Section AB

Description

Series[UMA-SR-000001021] Architectural drawings of Bates, Smart and McCutcheon Pty Ltd and predecessorsAccession[1968.0013] Consolidated records of Bates, Smart and McCutcheon Pty LtdPart of ItemThe Melbourne International Exhibition - Amended plan of "The Dome"IdentifierUMA-ITE-1968001300134Extent1 sheetScope and ContentSigned 'D.M' (David Mitchell). Additionally signed in pencil in top right corner, 'Traced by W.B.T' (William Brittain Tappin)Access StatusOpen for public accessRequest TypeRequest itemUnitUMA-SR-000001021 Unit 0125Copyright StatusPublic domainConditions of Use and ReproductionThis item is out of copyright. Please acknowledge the University of Melbourne Archives as the source of this material. For information about ordering a copy of this image contact the University of Melbourne Archives: archives@archives.unimelb.edu.auMenuBrowse digitised items | Available online

Provenance

CreatorReed & BarnesRoleArchitect

Provenance

CreatorBates, Smart and McCutcheon Pty LtdRoleProvenance

Contributor

ContributorMitchell, DavidContributor RoleContractor

Contributor

ContributorTappin, William BrittainContributor RoleDraftsperson

Dates

Date22 March 1879Date ContextDated on plan

Description Control

Previous System ID1968.0013.00134ClassificationUMA Job 30Other IDsDrawing number » 7
